Today let’s talk about one
of the best motorcycles ever made, the Honda CBR250RR MC22 also known as CBR
Gullarm.
Let’s talk a bit about the history of this
bike. Honda CBR250RR MC22 is based on MC14, MC17 and MC19 and was first
released in 1990 with a new improved look and technology. Brom 1990 to 1999 there
were 3 models of this bike with power output between 40 and 45BHP.
This bike was mainly
designed for the JDM market, also known as the “Japanese Domestic Market” this bike
was never directly imported by Honda to anywhere else, but 3rd party
resellers imported this bike all around the world. If we mention more similar
JDM bikes we can mention Honda Hornet 250, and Honda Jade 250.
Please refer below for model
numbers according to the manufactured year
1990 – Japan
Name:
Honda CBR250RR
Frame:
MC22-100~
Code: CBR400RR-L
1992 – Japan
Name:
Honda CBR250RR
Frame:
MC22-105~
Code: CBR250RR-N
1994-1999 – Japan
Name:
Honda CBR250RR
Frame:
MC22-110~
Code: CBR250RR-R
Engine, Power
output, Top speed
First, let’s talk about the engine, this bike is equipped with a 249cc Liquid-cooled 4-stroke 16-valve DOHC
in-line 4-cylinder engine. This engine can produce the max output that is
possible from a 250cc four-stroke engine. Because this engine is equipped with DOHC (Dual overhead camshaft) technology it can be more costly than other bikes in this
engine capacity.
This bike can produce up to
45BHP, and can reach 0-100 between 5-6 seconds. If we talk about top speed this
bike can reach up to 180kmph and sometimes even more than that. However, CBR
250 Fireblade model which was produced after 1994 was capped at 40BHP due to
legal reasons.
Cooling
As most of the 250cc bikes
that were produced by Honda at that time this bike is also equipped with a
liquid cooling system. Because this engine is 4 cylinders and 16 valves compared
to other 200cc – 250cc bikes this engine produced more heat, for this all,
liquid cooling was the most suitable cooling system. Cons of having a liquid
cooling system are that its so much costly than maintaining an air-cooled engine
and also in case of an accident these parts were very costly and hard to
replace.
Gear, Clutch,
fuel supply
(adsbygoogle = window.adsbygoogle || []).push({});
Honda CBR250RR is equipped
with a six-speed gearbox and a Wet multiple plate coil springs clutch. With
this clutch we can change gears in any speed without any noise. Fuel supply of
this bike is equipped with a 29mm Keihin Carburetor. We can expect up to 18-25
kmpl fuel efficiency with a 13-litter fuel tank and 1.6 litter reserve
capacity.
Design
If we talk about the design
of this bike, we can clearly see that Honda focused more on rider than the
passenger. The body fairing and all are designed to achieve high speeds while
maintaining stability. If you’re always riding with a passenger this is not the
bike for you. Because the passenger seat is located high and the foot pegs are also
located high. If you always ride with a passenger Honda Hornet 250 will match
your requirements better.
Full body kit of this bike
is manufactured with plastic and fiber. Because this bike was last manufactured
in 1999 there is no original body kits available in the market. If somehow you
get into an accident or broke your body kit you will have to make a fiberglass body kit or will have to settle for a Chinese body kit.
This bike is equipped with
an analogue meter panel. This is common for a bike that was built in the 90s.
this meter panel is equipped with RPM, speed ODO, trip and temperature gauges.
(adsbygoogle = window.adsbygoogle || []).push({});
As the head light Honda has used two 60/35-watt halogen lamp lights and 18/5-watt
tail lights with 15-watt signal lights.
Frame, chassis
With clip-on handle bars
rider can achieve high speeds while maintaining stability with a sporty riding
position, but the con is its so hard to ride this bike on traffic riding with
the riding position and turning circle is very small.
(adsbygoogle = window.adsbygoogle || []).push({});
Honda has equipped CBR250RR
with a diamond aluminium frame, which helps the rider with stability at high
speeds. When we try to hit RPM red line there is no any vibration or extra
noise. But when we ride the bike at red line RPM there is a slight vibration
from the body kit and handlebars.
Suspension,
breaks, tyres
Honda CBR250RR is equipped
with front 37mm Conventional Forks and rear mono shocks. These suspensions are commonly used in bikes
that were manufactured at that time.
If we talk about breaking
Honda has equipped 275mm double disc brakes with dual-piston nisin callipers. In
recent days front double discs are only equipped in high-capacity bikes only,
but with the 4cylinder 250cc engine double discs are a must and with these
breaks, riders can ride at top speed without thinking about breaks. With double
disks, we get safety and a sporty premium look. Rear brakes are equipped with
220mm single disc with a single nisin piston calliper.
Honda has equipped this bike
with 110/70 front tyres and 140/60 rear tyres with 17-inch alloy wheels.
At last, this bike is now
most suitable as a beginner bike or a collectable, because most of the bikes
that are on the market are older than 20 years and to find a bike without any
errors is so hard.
Hope you gained some
knowledge through this post. If you have any questions, please feel free to
contact us through Facebook.
Until the next post, be safe and
keep riding.
